    Chiller Hire

    SPECIFICATION
    Cooling Duty422Kw
    Input Kw137Kw
    Max Current324A
    RefrigerantR134a

    Operational Weight4461Kg
    Length4000mm
    Width2280mm
    Height2415mm

    • Built to Tranes high standards for exceptional reliability.
    • Two separate refrigeration circuits featuring Trane’s bullet proof Series R Helical Rotary Compressor.
    • Durable falling film semi- flooded evaporator- suited to industrial conditions.
    • Very efficient operation in all conditions.
    • Low GWP R134a refrigerant.



    • A clear level space for location of approximately 6.5x 5mt with a good access route for a rigid bodied truck with crane for locating the chiller.
    • A 390A tree phase supply. ACR can supply a suitable temporary connection. We use single core H07 RNF cable for our temporary supplies.
    • A minimum 4″ isolated flanged connection. ACR can supply 10bar rubber suction/ discharge hosing for connection between the machine and access point.
    • Secondary pumps available if required.
    • Full design, installation and commissioning provided.

    How to hire a 400kw chiller

    Hiring couldn’t be easier.

    1. Call or send an enquiry from the site to make contact with one of our professional engineers.
    2. With some basic information we can make a proposal for 400kw chiller hire with budget costs, and if required organise a site visit. Alternatively, if time is an issue, we have the experience to liaise remotely with on-site engineers to supply a solution quickly.
    3. When we have an order to proceed we will supply the equipment from stock to be installed by our engineering team. Our engineers will fully commission the installation and provide operational instruction.
    4. All our projects are covered by our 24/7 engineering support.

    Contact us now for friendly help and advice.

    Need help and advice with you project?

    Contact us
