    Air Handling Unit Hire



    Cooling/ heating duty 88/77kw
    Nominal air volume16,700M3/hr
    Additional electric heater dutyTBA
    AHU Max Current/ with electric heater80/134A
    Power input total heating/ cooling23/30kw


    AHU Weight 1365kg
    AHU- width 3890mm
    Depth 2250mm
    Height 1585mm


    1. Packaged design- the units feature a full AHU with a heating and cooling heatpump fitted.
    2. C02 monitoring and control of fresh air dampers for a safer working environment.
    3. Heppa filters fitted for additional filtration.
    4. Efficient fossil fuel free operation, including heating.
    5. Built into lifting frames for safe lifting and handling.
    6. Assured reliability, with full 24/7 engineering support and servicing.


    1. Space; a clear flat open space of around 4x 3.5mt.
    2. Power; a 3 phase 80A supply.
    3. Good access routes for delivery by HIAB lorry. Can be handled on-site with a suitable fork lift or tele-handler truck.

    Heat Pump AHU Hire in 5 Straightforward Steps

    1. Call or send an enquiry from the site to make contact with one of our professional engineers.
    2. With some basic information we can make a proposal for heat pump AHU hire with budget costs. If required we will organise a site visit. Alternatively, if time is an issue, we have the experience to liaise remotely with on-site engineers to get a plan together fast.
    3. When we have an order to proceed we will supply the heat pump from stock to be installed by our engineers.
    4. Our team will fully commission the installation and provide instruction on operation.
    5. 24/7 engineering support ensures reliability and peace of mind.

    Contact us now for friendly help and advice.
